Art No.

JSPC-200C

JSPC-300C

JSPC-420C

JSPC-960C

Chamber Volume (Capacity)

200 L

300 L

432 L

964 L

Dimensions

Inner

600x600x600

500x500x1200

600x600x1200

1200x600x1200

W x D x H mm

Outer

790x935x1385

690x835x1985

790x935x1985

1390x935x1985

Temperature

Range

Light Off : +0 ^oC ~ 60 ^oC   Light On :+10 ^oC ~ 60 ^oC w/o Humidification

Accuracy

± 0.3 ^oC at 20.0 ^oC, 60% RH (Light Off)

Uniformity

± 1.0 ^oC at 20.0 ^oC, 60% RH (Light Off)

Humidity

Range

30 ~ 98% RH (Sensor Range)   30 ~ 85% RH (Control Range)

Accuracy

± 3.0 % RH at 20.0 ^oC 60% RH

Uniformity

± 6.0 % RH at 20.0 ^oC 60% RH

Illumination

Range

0 ~ 30,000 Lux

Steps

8 Step Combination

Lamp

10 x 36W FPL

14 x 36W FPL

14 x 36W FPL

20 x 36W FPL

Configuration

Fluorescent Lamp

CO₂ Control

Conc. Range

ambient ~ 5,000 ppm (ambient ~ 20 %)

Accuracy

± 50 ppm

Controller

Programmable PID Control 11 segments 999 cycle repeatable

Sensors

Temp

Class A Pt-100 ? Sensor

Humidity

Electronic Humidity Sensor

CO₂

High Precision Dual Wavelength NDIR Diffusion Sensor

Light

Lux Meter

Number of shelves / Max. No.

3 / 11

3 / 35

3 / 35

6 / 35

Heater Capacity

3.0 kW

3.1 kW

3.5 kW

6.0 kW

Refrigeration System

CFC-Free Air Cooled Hermetically Sealed Compressor

Electric Requirement

220VAC 50/60Hz 1P

Power Rating

20 Amp

21 Amp

25 Amp

43 Amp

Power Plug

30 AMP

30 AMP

30 AMP

50 AMP
